Miniature-Microminiature Low Voltage Signal Control Cables

National Wire Miniature Microminiature Signal Control cables
National Wire & Cable Corporation manufactures a complete line of highly flexible micro-miniature low-voltage instrument control cable. These are available as cables pairs or singles, with optional overall shield. Conductors are stranded tinned copper with .010" wall of tough extruded polyvinyl chloride primary insulation, rated for 300 volt use at +80°C under U.L. style 1061*. All are color coded using ten standard colors plus white with stripes per MIL-STD-681.

Click on the products listed below for complete specifications and RFQ options.

NQ Series - Cabled Single Conductors Overall Braided ShieldedNon-RoHSRoHS
NQ Series - Cabled Single Conductors Overall Foil Shield with DrainNon-RoHSRoHS
NQ Series - Cabled Single Conductors UnshieldedNon-RoHSRoHS
NQP Series - Cabled Twisted Pairs Conductors UnshieldedNon-RoHSRoHS
NQP Series - Twisted Pairs Conductors Overall Braided ShieldedNon-RoHSRoHS
NQP Series - Twisted Pairs Conductors Overall Foil Shield with DrainNon-RoHSRoHS
NX Series - Cabled Single Conductors, Overall ShieldedNon-RoHSRoHS
NX Series - Cabled Single Conductors, UnshieldedNon-RoHSRoHS
NXP Series - Cabled Twisted Pair Conductors, Overall ShieldedNon-RoHSRoHS
NXP Series - Cabled Twisted Pairs Conductors, UnshieldedNon-RoHSRoHS

• Guaranteed Quality
• Short Runs are OK
• Optimum Flexibility
